Specifications | 13
3.0 Specifications
Electrical Specifications
3163-03 3163-04 3163-05 3163-06
Frequency
Range:
4 GHz to
8 GHz
8 GHz to
12 GHz
12 GHz to
18 GHz
18 GHz to
26.5 GHz
VSWR Ratio
(Avg):
3.2:1 Max
1.5:1 Avg
2.5:1 Max
1.5:1 Avg
2:1 Max
1.25:1 Avg
2:1 Max
1.25:1 Avg
Maximum
Continuous
Power:
250 Watts 250 Watts 200 Watts 50 Watts
Impedance
(Nominal):
50 Ω 50 Ω 50 Ω 50 Ω
Connectors: Type N (F) Type N (F) Type N (F) SMA (F)
Physical Specifications
3163-03 3163-04 3163-05 3163-06
Length
(Without
Mount):
60.0 cm
23.5 in
37.0 cm
14.6 in
39.0 cm
15.3 in
38.0 cm
14.8 in
Aperture
Diameter:
17.8 cm
7.0 in
10.2 cm
4.0 in
10.2 cm
4.0 in
10.2 cm
4.0 in
Weight:
1.8 kg
4.0 lb
0.5 kg
1.2 lb
0.6 kg
1.4 lb
0.5 kg
1.2 lb
