background image

Specifications

|

13

3.0 Specifications

Electrical Specifications

Frequency Range:

26 MHz

–1 GHz

Input Impedance (Nominal):

50

Ω

VSWR (Average):

2:1 above 80 MHz

Maximum Continuous Power

30 MHz

—60 MHz:

500 W

60 MHz

—600 MHz:

1 kW

600 MHz

—1000 MHz:

500 W

Peak Power:

1.3 kW

Pattern Type:

Directional

Polarization:

Linear

Connector:

Type N female

Physical Specifications

Height (Overall):

76.2 cm (30 in)

Length:

124.35 cm (48.96 in)

Width:

133.75 cm cm (52.66 in)

Weight:

5.5 kg (12 lb)
