www.ets-lindgren.com Specifications 11
3.0 Specifications
Electrical Specifications
VSWR Ratio (Average) <5:1 Typical
Max. Continuous Power 1 Watt
Impedance (Nominal) 50 Ohms
Connector SMA
The symmetry is guaranteed over a 10MHz span less than 1880 MHz,
above that frequency the symmetry is only guaranteed at the nominal
frequency.
Physical Specifications
Diameter A: 1.9 cm (0.75 in)
Diameter B: 12.7 cm (5.0 in)
Length: 21.6 cm (8.5 in)
All units are the same size except for those units under 700 MHz.
