Mounting Instructions | 17
5.0 Mounting Instructions
Before connecting any components, follow the
safety information in the ETS-Lindgren
Product Information Bulletin included with your
shipment.
Using Included Mounting Adapters on a 4-TR
The Model 3104C ships with the following adapters, used to mount the antenna
to a 4-TR tripod:
• 102108 Clamp Block—Uses
standard 7/8–14 threads and comes
with a 1/4–20 thread adapter for
mounting to an ETS-Lindgren tripod
or most other tripods.
• 100733 Support Rod
• 101942B Support Base
