P o w e r f u l S o u n d P r e s e n t a t i o n S o l u t i o n s ™
Califone ® International Inc.
(800)722-0500
Visit Us online at califone.com
Speaker System Bass reflex design tuned to 50 Hz
Woofer 10” diameter, 2” diameter voice coil, 40 ounce magnet is most efficient in its
class (increases volume & means speaker doesn’t need to work as hard as
one with a smaller magnet), moisture resistant cone with 120 Watt Capacity
Horn Tweeter 4.25” square, 12 ounce magnet, 1” diameter voice coil, 30 Watts RMS
capacity, phenolic diaphragm, moisture resistant
Crossover Network 3 kHz @12 dB/Octave, air core inductors, Mylar/Low DF capacitors,
fiberglass P.C.B. circuit
Frequency Response 45 Hz to 18 kHz
Sound Pressure Level 94 dB, 1 Watt @ 1 Meter
Mechanical Features
Rear Panel
Angled for easier accessibility and viewing
Enclosure Fiberglass-reinforced polypropylene
Grille 1.5mm steel with powder-coated finish
Tripod Mount Recessed into bottom, molded at optimum center of gravity
Dimensions 24”h x 14”w x 14”d
Weight 34 pounds
Warranty 6 years for amplifier
Safety Compliance Meets RoHS and WEEES standards
4-position
telescoping
steel handle
Unbalanced mic /
sourceinput (1/4”)
Rugged go-anywhere
3.5” wheels move
easily on pavement,
grass and dirt
Steel Skid Guards
prevent damage
while hauling
on stairs
PowerPro Non-Powered Support Speaker
Accessories
Ship Wt.
Speakers The PowerPro and PresentationPro (PA300+UHF) speakers share the
same wireless frequencies and can be used together!
PA-916 Powered Wireless PA system, (2) 16-channel UHF true diversity, CD Player,
PLL wireless receiver, 90 Watts RMS, Fully programmable variable speed
Cassette Player/Recorder, (2) Combination XLR / 1/4” Mic Inputs, Speaker Mute,
Switched/Unswitched speaker out, Voice Priority Switch, Voice Music Switch,
Separate Treble and Bass Controls, Digital Master Volume Control, 6’ Power
Cord (3-Wire for safety)
52 lbs.
PA916-PS Powered Companion Speaker, one 16-channel UHF true diversity
PLL wireless receiver, 90 Watts RMS, Separate Treble and Bass Controls,
Digital Master Volume Control, 6’ Power Cord (3-Wire for safety) 47
Wired Mics
PADM-510
Dynamic, Lo-Z handheld mic, 15’ cable, 1/4” phone plug 2
Transmitters/Receivers share Wireless frequencies with PowerPro and PresentationPro Mics & Systems!
TR-16 Wireless transmission from any media source, 16-channel UHF 10
R-16 Turns any wired speaker into a Wireless Receiver, 16-channel UHF 10
Misc. Mic Stands / Cables / Remote Control
TP-50
Adjustable tripod 11
C-TP50 Heavy duty nylon carry case for TP-50 tripod 2
SC-50 Speaker cable (50’) for passive speaker 2
K-201-1 Mic floor stand 7
PSC-50 Bus cable for powered speaker 2
K-415 Mic holder to use with PADM-515 1
RC-300 Remote Volume/Mute Control for PowerPro / PresentationPro Series PA units 1
Recessed
Tripod Mount
C-UL approved for assurance
of safety when used in schools,
businesses and government
facilities
October, 2004
Distributed by:
P o w e r P r o
NON-POWERED SUPPORT SPEAKER PA916-SP
P R O D U C T O V E R V I E W
