• When switching the appliance off, never use the cable to remove the plug from the mains socket.
Always hold the plug and pull it from the socket.
• Before cleaning the appliance, always remove the plug from the mains socket and turn off the steam by
rotating the steam flow control clockwise (to CLOSE).
• Do not leave water in the tank for a long time.
• Only fill or drain the water tank if the appliance is switched off and disconnected from the mains.
Please keep this instruction manual. If you give the appliance to anyone else,
you must give them this instruction manual, too!
MAIN COMPONENTS
1 Grip
2
Short (upper) handle piece
3 Long (lower) handle piece
4 Handle inset
5 Handle socket (on appliance casing)
6 Cable holders
7 Cable clip
8 Steam flow control
9 Lamp (red indicates heating / green indicates readiness)
10 Water tank cap
11 Water
inlet
12 Steam head
13 Power cable with plug
14 Cleaning
mop
15 Measuring cup for water (not shown in the illustration)
POWER SUPPLY
The appliance must only be connected to 230V~ 50Hz mains electricity with a protective earth
connection. Always ensure that the mains voltage where you’re using the device corresponds to
the value shown on the appliance.
STMP-2234
8
PREPARING THE STEAM MOP
1. Unpack the appliance and remove all the packing materials.
Never leave the nylon storage bag within the reach of children who could play with it.
2. Carefully inspect the appliance and the accessories to make sure everything is complete and undamaged.
You should only use the appliance if it is complete and has not suffered any damage.
3. Assemble the handle.
a) Slip the grip (part no.1) onto the shorter handle piece (part no.2) so that the lugs coincide with
the holes on the side of the grip. Fit the lugs into the holes to attach the grip.
b) Insert the longer handle piece (part no.3) into the socket on the appliance (part no.5) so that
the lugs face outwards, towards the open part of the socket. Insert the handle as far as necessary
to fix it firmly in the hole on the casing.
c) Connect the handle piece with the grip (parts 1 and 2) to the rest of the appliance by using
the plastic inset (part no.4). Turn the handle pieces when attaching them to the inset so that
the grip is positioned correctly.
d) Clip the power cable into the cable clip (part no.7) on the grip.
Do not use excessive force or sharp movements when assembling the handle as this could break
the handle or the socket. The manufacturer accepts no liability for damage or breakage caused by
forcing the parts.
EN
