Wiring diagram
Top of the unit showing cable connections
6. SETTING PREFERENCES
Accessing the on-screen display menus
1. Press
SETUP on the remote to access the OSD menus.
The main Display menu appears.
General setup page
VT800B/VT1000B/VT1000T/VT1500B
A
V OUT
A
V IN 2
B+ (YELLOW)
ACC (RED)
GND (BLACK)
DOOR (GREEN)
AV 1 IN
Polarity switch
