GENERAL SAFETY RULES
WARNING!
1. Check for damaged parts. BEFORE
using the Arrow Saw, check that all parts
are operating properly and perform their
intended functions. Check for alignment
of moving parts, binding of moving parts,
and any other condition that may affect the
Arrow Saw operation.
2.
ALWAYS DISCONNECT Arrow
Saw from power source before servicing,
changing accessories or cleaning the unit.
3. To Reduce risk of unintentional starting,
make sure the power switch is in the “OFF”
position before connecting the Arrow Saw
to the power source.
4. DO NOT IMMERSE THE ARROW
SAW INTO WATER OR OTHER LIQUID,
OR OPERATE NEAR A WATER SOURCE.
SERIOUS INJURY FROM ELECTRIC
SHOCK COULD RESULT.
5.
DO NOT operate the Arrow Saw with
wet hands or bare feet.
6. The Arrow Saw is not a toy. KEEP
CHILDREN AWAY from the unit at ALL times.
NEVER LEAVE THE UNIT UNATTENDED
DURING OPERATION.
7. Keep fingers clear of the
Cutting Blade
at all times. NEVER reach into the Arrow
Saw with fingers or other objects. Doing
so may result in personal injury or unit
damage.
8. Any improper use or modification of
the Arrow Saw will void the warranty.
9. DO NOT attempt electrical repairs. Any
electrical repair must be done by an authorized
service technician. If your Arrow Saw
needs repairing, contact Customer Service.
10. DO NOT operate the Arrow Saw if
it is damaged or malfunctions in any way.
Instead, please call Customer Service.
11. Tie back loose hair and clothing, roll
up long sleeves, and remove ties and rings,
bracelets and other jewelry before operating
the Arrow Saw.
12. DO NOT use the Arrow Saw if the
power cord is frayed or damaged in any
way.
13. Keep the power cord well clear of the
Arrow Saw blade during operation.
14.
DO NOT operate Arrow Saw while
under the influence of drugs or alcohol.
15. The Arrow Saw is for household use
only. Commercial use of the Arrow Saw will
void the warranty.
16. Only operate the Arrow Saw on a flat,
stable work surface.
17. NEVER install any accessories or parts
from other manufacturers on the Arrow
Saw. Doing so may damage the unit and
will void the warranty.
18. ALWAYS make sure the Cutting
Blade is properly secured before operating
the Arrow Saw. Always stand clear of the
Cutting Blade during start up.
19.
ALWAYS clean the area near the
Cutting Blade. Keep it clear of dust and
debris to prevent damaging the blade.
20. Wear eye protection at all times
while the Arrow Saw is in use. Everyday
eye glasses are not safety glasses. Safety
glasses confirm to ANSI Z87.z requirements.
Approved safety glasses have Z87 printed
or stamped on them.
SAVE THESE INSTRUCTIONS!
Refer to them to instruct others.
READ AND FULLY UNDERSTAND ALL
INSTRUCTIONS AND WARNINGS PRIOR TO
USING THIS SAW. YOUR SAFETY IS MOST
IMPORTANT! FAILURE TO COMPLY WITH
PROCEDURES AND SAFE GUARDS MAY
RESULT IN SERIOUS INJURY OR PROPERTY
DAMAGE. REMEMBER: YOUR PERSONAL
SAFETY IS YOUR RESPONSIBILITY!
-4-
FIGURE 8
Arrow Shaft
Shaft Position
Bracket
Cutting Blade
Arrow Shaft
Guide
12. Place the nock/insert end of the arrow shaft into the notch in the Shaft Position
Bracket. Figure 8
13. Gently guide the end of the arrow shaft to be cut into the Cutting Blade until it is
completely cut. Figure 8
14. Carefully remove the cut arrow shaft from the Arrow Shaft Guide and Shaft
Position Bracket. Be careful to not allow the arrow shaft to further contact the Cutting
Blade.
15. Turn the
Arrow Saw to the ‘OFF’ Position. Turn off the attached vaccuum.
Disconnect from the power source when not in use.
-9-
1. Set the On/Off Power Switch to
the “OFF” position. Disconnect the
Power Cord from the power source.
2. Loosen the two Thumb Screws holding the
Blade Shield to the Arrow Saw. Figure 9
3. Remove the Thumb Screws and Blade
Shield.
4. Using an Allen Wrench, loosen, but do not
remove, the Socket Head Cap Screw securing
the Arrow Shaft Guide to the Base.
Figure 10
5. Adjust the Arrow Shaft Guide until the Cutting
Blade extends about halfway through the arrow
shaft. Figure 7
6. Firmly tighten the Socket Head Cap Screw
to secure the Arrow Shaft Guide to the Base.
7. Replace the Blade Shield. CAUTION:
NEVER OPERATE THE ARROW SAW
WITHOUT THE BLADE SHIELD SECURELY
MOUNTED IN PLACE!
FIGURE 9 Blade Shield
Thumb Screws
FIGURE 10
Arrow Shaft
Guide
Arrow Shaft
Guide
Socket Head
Cap Screw
Base
Cutting
Blade
Halfway
through
the
arrow
shaft
ROLL CUTS
WARNING!
Before cleaning, assembling or disassembling the Arrow
Saw, make sure it is turned OFF and the PLUG IS REMOVED FROM THE
OUTLET/POWER SOURCE!
CAUTION ROTATING SHARP BLADE!
To avoid severe injury keep fingers, hands and other foreign
objects clear of the saw opening Blade and Moving Parts of the
Arrow Saw. Wear approved Safety Glasses and Kevlar Gloves
when using the Arrow Saw.
