33
MODEL 3 ZONES
Upper control unit
Lower control unit
Power
To turn this appliance on/off, press the bottom and hold for 5 seconds. Pressing the key once can switch off
the audible alarm when the alarm is on.
LIGHT
To control the inner light turn on/off.
« UP »
Used to increase (warm) the set temperature by 1°C/1°F.
« DOWN »
Used to decrease (cool) the set temperature by 1°C/1°F.
SELECTOR
Select the temperature display setting in Fahrenheit or Celsius degree. To change the temperature from Fahrenheit to
Celsius or from Celsius to Fahrenheit, press the button for 5 seconds
SETTING THE TEMPERATURE CONTROL
The wine cooler has three temperature zones. The temperature of all zones can be set separately.
The temperature settings of UPPER ZONE are adjustable with the range +14°C et +22°C (+57°F et +72°F), the preset
temperature at the factory is 18°C/65°F.
The temperature settings of MIDDLE ZONE are adjustable with the range 5º-11ºC/40º-52ºF. The preset temperature at the
factory is 8ºC / 46ºF.
The temperature settings of LOWER ZONE are adjustable with the range 11º-13ºC/52º-56ºF. The preset temperature at the
factory is 12ºC / 54ºF.
Temperature control for upper and middle ZONE at upper control unit. Temperature control for lower ZONE at lower control
unit.
•
To view the “set” temperature in either zone at any time, touch the UP or DOWN mark, the “set” temperature will
temporarily “flash” in the LED display for 5 seconds.
