Dimension Data in Inches
Self Contained
A
68.4
N
29.1
B
22.2
O
24
C
45.5
P
8.3
D
21.6
Q
23.1
E
16.8
R
12
F
19.9
S
11.5
G
5.0
T
27.1
H
11
U
10.6
I
47.75
V
16.5
J
5.5
W
14.4
K
8.4
X
11
L
37.7
Y
25.7
M
45.6
Z
14.4
T
S
W
R
N
O
Q
X
V
A
B
C
D
E
H
G
F
U
P
L
K
Y
I
J
M
Dimensional Data
Self-Contained Configuration
