Mini Card to USB Adapter User’s Manual

Page 2

1.0 Introduction

The USBMA adapter is designed for desktop PCs that convert Mini-Card to
USB port.
You can insert your USB type mini card such as HSDPA (3.5G), GPS,
802.11a/b/g to this adapter then plug to USB port through USB cable.
Standard SIM card connector is provided

2.0 Interface

Mini Card to USB adapter as shown,

Figure-1 Mini Card to USB Adapter (heads)

Figure-2 Mini Card to USB Adapter(back)

LED State:

When the user plugs mini card into Mini Card to USB Adapter, LED D1 (Y) is
