3. Press “LAN Configuration”.
4. And In the drop-down list “Obtain IP address”, choose
“Static IP”.
5. Manually input the “IP address”, “Subnet Mask” and
“Default Gateway”.
6. Select “Apply” and press
(
Enter).
7. Press (Back) on the remote to return to previous
menu. (If you have H.323 ALG enabled, skip to step 10).
8. In the same page, go to “Firewall” and press (Enter).
9. Select “ON” in the NAT check box and enter the IP address
in the “NAT Public (WAN) address” field.
10. Press the “Home” button on the remote to return the home
menu.
11. Press the Call button on the remote and you are
ready to make your first call.
Scenario 3
– H.460 Gatekeeper with Firewall Traversal
Your EVC is connecting to the internet through a firewall and you have a Gatekeeper outside the firewall.
EVC Firewall
Gatekeeper
Internet
1. From the remote press “Home”-> -> “Setting”.
2. Press -> “Network”.
