AVer U15 - Manual (Page 2)

Connecting the External USB Device to AVerVision U15
USB Mouse
USB Flash Drive
Connecting a Power Adapter (Optional)
Connect a power adapter to a standard 100V~240V AC power outlet.
The power from the computer USB is sufficient enough to power AVerVision U15. However, if your laptop or desktop
USB port does not supply as much power as the USB specification says it should, then you may encounter problems
and need an external power supply.
The symptoms of insufficient power are typically the U15 randomly appearing and disappearing from Device Manager,
and accompanying beeps. If a power supply is required, the specification for the power adapter is 5Vdc, 3A.
Power adapter
Wall outlet
General Specification
Sensor CMOS
Pixel Count 2 megapixels
Frame Rate 30 fps (max.)
TV Lines 600 (center)
Resolution
1920x1080, 1280x720,
1024x768, 640x480
Optics
Focusing Auto
Shooting Area
431mm x 254mm @ 475mm height
17.7in x 10in @ 18.7in height
Zooming 8X Digital Zoom
Power
Power Source
DC 5V (3A), 100-240V, 50-60Hz from host
equipment or adapter (optional)
Consumption 1.9 Watts (lamp on); 1.7 Watts (lamp off)
Lighting
Lamp Type LED light
Input/Output
USB mini
Power and signal connectivity to host
equipment
USB Hub (2x) USB2.0
DC 5V Input Power Jack
MIC Built-in
Dimension
Operating
390mm x 248mm x 447.5mm (+/-2mm
include rubber foot)
Folded
259mm x 163mm x 38.79mm (+/-2mm
include rubber foot)
Weight 1.5KG (about 3.306lbs)
For detailed warranty information, please visit our website http://www.aver.com and select the country where
the unit is purchased.
