7
the other end into the rear of the receiver. See Fig. 11.
b. Turn on the receiver. The LED on the front of the unit should light
up.
Other Applications
Using Remote Control
The Wireless A/V Sender gives you the ability to control A/V components from
another room using your existing remote control device. To use this function,
follow the steps below:
1. Place the transmitter next/close to the A/V source component and plug the
IR eye into the jack located on the rear of the transmitter (IR Eye plug).
Adhere the IR eye directly to the IR window on the front of the source
component (see Fig. 12) OR place the IR eye in front of the source
component (see Fig. 13).
Fig. 11
Wall Outlet
Fig. 12
Receiver
POW ER
ON-OFF
Receiver
TV
Remote Control
AV Source
Component
Transmitter IR Eye
Fig. 13
AV Source
Component
