Connecting the Device
1.
Use an HD15 male to male cable to connect your monitor or
projector to the HD15 female port with the picture of a monitor
under it.
2.
Use HD15 male to female cables to connect your computers to
the HD15 male ports labeled 1-2 or 1-4.
3.
Connect the power adapter to the port labeled DC 5V and
connect the adapter to a power outlet.
4.
Use the push buttons on the front of the device or the IR remote
control to switch the video signal sent to your monitor or
projector.
5.
The LED above the push button on the front of the device will
light green to indicate which computer is selected.
6.
Turn the on/off the device and your monitor by switching on/off
the red toggle switch on the front of the device.
