3
9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes
Configuration
ID
FDDI Connections Description
1 FNB 1 Pri. (MAC) Byp. ,
FNB 2 Pri. (No MAC) Byp.
The module is attached, but not inserted, to
the primary ring on the FNB-1. The module is
attached, but not inserted, to the primary ring
on the FNB-2. The MAC resides on FNB-1.
2 FNB 1 Pri. (MAC) Byp. ,
FNB 2 Pri. (No MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned off. The switch that inserts the module
into the FNB-2 is turned on. The MAC resides
on FNB-1.
3 FNB 1 Pri. (MAC) Ins. ,
FNB 2 Pri. (No MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned on. The switch that inserts the module
into the FNB-2 is turned off. The MAC resides
on FNB-1.
4 FNB 1 Pri. (MAC) Ins. ,
FNB 2 Pri. (No MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned on. The switch that inserts the module
into the FNB-2 is turned on. The MAC resides
on FNB-1.
5 FNB 1 Pri. (No MAC) Byp. ,
FNB 2 Pri. (MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned off. The switch that inserts the module
into the FNB-2 is turned off. The MAC resides
on FNB-2.
6 FNB 1 Pri. (No MAC) Byp. ,
FNB 2 Pri. (MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned off. The switch that inserts the module
into the FNB-2 is turned on. The MAC resides
on FNB-2.
