DUAL ROD DECK SUSPENSION TRACTORS
IMPORTANT:
These instructions are for tractors with duai
mower deck suspension brackets iike the exampies shown
in figure 2 on this page..
A
CAUTION!
Muffler is hot! Aiiow engine to
cooi down before proceeding with bumper
instaiiation.
STEP 1:
(SEE FIGURE 1)
•
Remove tractor hood. (Refer to tractor manuai.)
•
Remove an (LT) Lawn Tractor heat shieid iike the one
shown. Remove a (GT) Garden Tractor heat shieid
iike the one shown oniy if you need access to inside
of tractor frame during step 2.
IMPORTANT: Be sure to re-attach
the heat shield after
bumper is instaiied.
STEP 2:
(SEE FIGURE 2)
•
Remove any boits present in front mounting hoies in
side of tractor frame. If bolt will not screw out of hole,
check if a nut is present on boit on inside of frame.
On GT tractors, if access to nut is biocked by a front
mounted muffler, slide muffler down exhaust tubes to
rest on top of browning shield.
IMPORTANT: Be sure to re-attach
muffler and heat
shield after bumper is instaiied.
•
If rear mounting hoies in tractor frame are empty,
instaii hex boits (C) and hex nuts (D) suppiied in parts
bag. See figure 2.
FIGURE 1
