TRACTOR - MODEL NUMBER 917^58010
GROUND DRIVE
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
-j
T ransaxle Dana D4360-139 48 154407 Bellcrank Asm. Clutch
(Order parts from transaxle 49 123205X Retainer Belt Style Spring
Manufacturer) 50 74760624 Bolt Hex Hd 3/8-16unc x1-1/2
2 146682 Spring Return Brake T/a Zinc 51 73680600 Nut Crownlock 3/8-16 UNC
3 123666X Pulley Transaxle 18/20' tires 52 73680500 Nut Crown Lock 5/16-18
4 12000028 Ring Retainer #5100-62 53 105710X Link Clutch 7 66
5 121520X StrapTorque 30 Degrees 55 105709X Spring Return Clutch 6 75
6 17000512 Screw 5/16-18 X 3/4 56 17060620 Screw 3/8-16x1-1/4
7 162240 Bracket Saddle Shift T/a 57 160855 V’BeltQd Drive 9530
8 131679 RodShfSdILY/YTStrBIk 59 169691 Keeper Belt Centerspan
10 76020416 Pin Cotter 1/8 X 1 Cad 61 17120614 Screw 3/8-1 6 X . 875
11 105701X Washer Plate 388 Sq Hole 62 8883R Cover Pedal BIk Round
12 19151216 Washer 15/32 X 3/4 x16ga 63 ire4io Pulley Eng Cl Cable
13 74550412 Bolt 1/4-28unf Gr8 W/Patch 64 71170764 Bolt Hex 7/16-20 X 4 Gr 5
14 10040400 Washer Lock Hvy Helical 1/4 65 10040700 Washer Lock Hid Spr 7/16
15 74490544 Bolt Hex Rghd 5/16-18 x Gr. 5 66 154778 Keeper Belt Engine FP
18 74780616 Bolt Fin Hex 3/8-16 UNC x 1 Gr. 70 134683 Guide Belt Mower Drive RH
5 74 109502X Spacer >\xle
19 73800600 Nut Lock Hex W/lns. 3/8-16 Unc 75 121749X Washer 25/32 x 1-1/4 x16 Ga
21 106933X Knob Rd 1/2-13 Piste Thds 76 12000001 E-ring #5133-75
22 130804 Rod Brake BIk Zinc 26 840 77 123S83X Key Square 2 0 x 1845/1665
24 73350600 Nut Hex Jam 3/8-16 Unc 78 121748X Washer 25/32 x1-5/8 x 16 Ga
25 106888X Spring Rod Brake 2 00 Zinc 79 222SM Key Woodruff #9 3/16 x 3/4
27 76020412 Pin Cotter 1/8 X 3/4 Cad 96 4497H Retainer Spring 1
28 175765 Rod Brake Parking Lt/Yt 112 19091210 Washer 9/32 x 3/4 x 10 Ga
29 71673 Cap Brake Parking 113 127285X Strap Torque LH LT
30 174973 Bracket Mig Transaxle 116 72140608 Bolt 3/8-16 X 1
32 74760512 Bolt Hex Hd 5/16-18unc x 3/4 119 19131016 Washer 13/32 X 5/8 x 16 Ga
34 175578 Shaft/^m Pedal Foot Nibbed 120 73900600 Nut Lock Rg 3/8-16
35 120183X Bearing Nylon BIk 629 Id 150 175456 Spacer Retainer
36 19211616 Washer 21/32 x 1 x 16 Ga 151 19133210 Washer 13/32x2x lOGa.
37 1572H Pin Roll 3/16 X r 170 178394 Keeper Belt Transaxle Gear
38 179114 Pulley Composite Rat 202 72110614 Bolt Carr. Sh 3/8-16 x 1-3/4 Gr. 5
39 74760648 Bolt Rn Hex 3/8-16 UNC x 3 Gr. 212 145212 Nut Hex Range Lock
5 250 17060612 Screw 3/8-16 X 3/4
41
47 175556
127783 Keeper Beit Idler
Pulley Idler V Groove Plastic
NOTE: All component dimensions given in U. S.
inches 1 inch == 25.4 mm
37
