Craftsman 580.763000 - Manual (Page 19)

PARTS
CRAFTSMAN 3000 PSI HIGH PRESSURE WASHER 580.763000
ITEM PART NO. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
7 78653 Run/Stop Switch {1 req.) 20 72347 Spark Plug» (1 req.)
8 85272 LE.D. Assembly (1 req.) 21 86962 Governor Lever (1 req.)
9 84195 Low Oil Shutdown Decal (1 req.) 22 85953 Wear Washer (1 req.)
10 85620 Black Sleeving (1 req.) 23 83502 Adjust Screw (1 req.)
12 84329 3-pin Male Connector 24 83512 M8 X 15mm Taptite
Housing (1 req.) Screw (1 req.)
13 00185271 White Wire Assembly (1 req.) 25 78604 Governor Spring (1 req.)
14 22097 M6 Lock Washer (2 req.) 26 66476 M6x 12mm Capscrew {1 req.)
15 82891 M6 X 30mm Screw {2 req.) 27 83503 M5 Lock Nut (1 req.)
16 81675 Ignition Coil (1 req.) 28 83781 Governor Bracket {1 req.)
17 84274 Tinnerman Clamp (1 req.) 29 85384 Governor Rod (1 req.)
18 87221A Low Oil Shutdown 30 86037 Anti-lash Spring (1 req.)
Module (1 req.)
19 45756 M6 X 10mm Screw (1 req.)
19
