REPAIR PARTS
ROTARY LAWN MOWER - - MODEL NO. 917.379480
GEAR CASE ASSEMBLY PART NUMBER 702511
KEY PART
KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 17490416 Tapping Screw 1/4*20 x 10 57079 Hardened Washer
1-1/4 11 131484 Clutch Yoke
2 137055X004 Engagement Bracket 12 700343 Bushing
3 137053 Shifter
13 86447 Plug
4 57072 Seal 14 137050 Helical Gear
6 48373 Gear Case Halves Kit
15 750436X Clutch Jaw
(Includes Key Nos. 4, 16 750369 Grease
and 7)
17 12000003 E-Ring
7 77881 Bearing
18 850848 Hi-ProKey
8 137051 Worm Shaft
19 81585X004 Spring Bracket
9 137074 Drive Shaft
NOTE: All component dimensions given
in U.S. inches. 1 inch = 25.4 mm
