13
Stardance Direct Vent/Natural Vent Gas Heater
20012734
Venting Requirements and Options -
Direct Vent ONLY
Approved Vent System Components
The Stardance Heater must be vented to the outdoors
through an adjacent exterior wall or through the roof.
The venting system must be comprised of the appropri-
ate listed venting components specified on this page.
These parts are available from DuraVent Corporation,
Selkirk Corporation or your Vermont Castings Dealer.
See Figure 4 for dimensions relevant to the standard
minimum-vent kits.
Simpson DuraVent Components
www.duravent.com
Phone: 1-800-835-4429, Fax: 1-707-446-4740
Minimum Horizontal Vent Kit 2792
Starter Pipe Assembly (incl. inner & outer sections) 2768*
90° Elbow, Blk. 46DVA-E90B*
45° Elbow, Gal. 46DVA-E45
6” Straight, Blk. 46DVA-06B*
9” Straight, Blk. 46DVA-09B
11” - 14⁵⁄₈” Adjustable Straight Section 46DVA-08AB
12” Straight 46DVA-12
24” Straight 46DVA-24B*
36” Straight 46DVA-36B
48” Straight 46DVA-48
Horizontal Vent Cap 46DVA-HC*
Wall Plate 46DVA-DC
Vinyl Siding Shield 46DVA-VSS
Snorkel Termination - 14” 46DVA-SNK14
Snorkel Termination - 36” 46DVA-SNK30
Wall Strap 46DVA-WS
Cathedral Ceiling Support Box 46DVA-CS
Storm Collar 46DVA-SC
Firestop Spacer 46DVA-FS
Flashing 0/12 - 6/12 46DVA-F6
Flashing 6/12 - 12/12 46DVA-F12
Steel Chimney Conversion Kit
Kit A (6⁵⁄₈” - 8⁵⁄₈”)
46DVA-KCA
Kit B (6⁵⁄₈” - 10¹⁄₂”) 46DVA-KCB
Kit C (6⁵⁄₈” - 13”) 46DVA-KCC
Masonry Chimney Conversion Kit 46DVA-KMC
Vertical Termination Cap (High Wind) 46DVA-VCH
Vertical Termination Cap (Low Profile) 46DVA-VC
*Included in Minimum Horizontal Vent Kit #2792
All DuraVent Straight vent pipe sections have a net
length 1¹⁄₂” (37mm) less than the nominal dimension;
i.e., a 6” (152mm) Straight pipe section has an effective
length of 4¹⁄₂” (115mm).
Selkirk Corporation Vent Components
www.selkirkcorp.com
1301 W. President George Bush Highway Ste. 330
Richardson, TX 75080
Phone: 1-800-992-8368, Fax: 1-877-393-4145
Appliance Adapter 4DT-AAV
90° Elbow, Blk. 4DT-EL90B
45° Elbow, Blk. 4DT-EL45B
6” Straight, Blk. 4DT-06B
9” Straight, Blk. 4DT-09B
4” - 10” Adjustable Straight Section Blk. 4DT-AJ12B
12” Straight, Blk. 4DT-12B
18” Straight, Blk. 4DT-18B
24” Straight, Blk. 4DT-24B
36” Straight, Blk. 4DT-36B
48” Straight, Blk. 4DT-48B
Horizontal Termination 4DT-HC
Wall Thimble 4DT-WT
Vinyl Siding Standoff 4DT-VS
Snorkel Termination - 14” 4DT-ST14
Snorkel Termination - 36” 4DT-ST36
Wall Support Band 4DT-WS/B
Cathedral Ceiling Support Box 4DT-CCS
Storm Collar 4DT-SC
Firestop Spacer 4DT-FS
Flashing 0/12 - 6/12 4DT-AF6
Flashing 6/12 - 12/12 4DT-AF12
Steel Chimney
Horizontal Kit A
4DT-HKA
Horizontal Kit B 4DT-HKB
Vertical Kit 4DT-VKC
Masonry Chimney Kit 4DT-MCK
Vertical Termination Cap 4DT-VC
NOTE: Direct vent pipe may be used on the Natural
Vent system from the top of the draft hood adapter to
the ceiling.
