TRACTOR - MODEL NUMBER 917.271554

SCHEMATIC

IGNITION SWITCH

SPARK

plug

GAP •

(2 PLUGS ON

TWIN CYL. ENGINES)

2S VOLTS AC MW. S 3600 №u
{CHARQINO SYSTEM DISCONNECTEO^

FUEL SHUT-OFF SOLENOID ,-------- 5S£.

(IF SO EQUIPPED) r

-------------------------------------------------------------------1 UGHTINQ SYSTEM OUT
^____________________ OHANCE__________ 5 AMP AC a 3B0Q HPM

NOTE

YOUR TRACTOR IS

EQUIPPED WITH A SPECIAL

ALTERNATOR SYSTEM.
THE LIGHTS ARE NOT

CONNECTED TO THE
BATTERY, BUT HAVE THEIR
OWN ELECTRICAL SOURCE.
BECAUSE OF THIS, THE
BRIGHTNESS OF THE LIGHTS

WILL CHANGE WITH ENGINE

SPEED. AT IDLE THE LIGHTS

WILL DIM. AS THE ENGINE IS

SPEEDED UP, THE LIGHTS

WILL BECOME THEIR BRIGHTEST.

POSITION

CIRCUIT

"MAKE”

OFF

M+G-

NONE

RUN/LIGKT

B-fAl

A2+L

RUN

B+A1

NONE

START

B + S +A1

NONE

NON-REMOVABLE

CONNECTIONS

REMOVABLE

CONNECTIONS

WIRING INSULATED CLIPS

NOTE: IF WIRING INSULATED CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY SHOULD BE REPLACED TO
PROPERLY SECURE YOUR WIRING,
