CRAFTSMAN BELT SANDER ~ MODEL NUMBER 315.117260
The model number will be found on a plate attached to the motor housing. Always mention the model
number in ail correspondence regarding your BELT SANDER or when ordering repair parts.
SEE BACK PAGE FOR PARTS ORDERING INSTRUCTIONS
PARTS LIST
Key Part
No. No. Description Qty.
1 940211009 Logo Plate................................................................................. ......................................... 1
2 “kick Sanding Belt.............................................................................. ......................................... 1
3 300027035 Dust Collection Bag................................................................... ......................................... 1
4 690711001 Wear Plate................................................................................ ......................................... 1
5 590477001 Belt Cover................................................................................. ......................................... 1
6 660312001 * Screw (8-32 x 3/8 in.) * ** ‘STD510803........................................ ......................................... 2
7 940301004 Data Plate................................................................................. ......................................... 1
8 590560001 Beit............................................................................................ ......................................... 1
9 900720001 Backing Pad.............................................................................. ......................................... 1
10 660272001 * Screw (M4
X
14 mm)................................................................... ......................................... 1
11 590481001 Tracking Knob........................................................................... ......................................... 1
12 690725001 Spring........................................................................................ ......................................... 1
13 680771001 Washer...................................................................................... ......................................... 1
14 660212013 * Screw (M4
X
14.5 mm)............................................................... ......................................... 2
983000-260 Operator's Manual
* Standard Hardware Item - May Be Purchased Locally
** Available From Div. 98 - Source 980.0
Complete assortment available at your Nearest SearsRetail Store
17
