CRAFTSMAN CIRCULAR SAW — MODEL NUMBERS 315.108330 / 315.108340
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
CIRCULAR SAW or when ordering repair parts.
SEE BACK PAGE FOR PARTS ORDERING INSTRUCTIONS
PARTS LIST
Key Part Key
t
Part
No. Number Description Quan. No. Number
1 974542-001 Data Plate (Model No. 315.108330)... ........... 1 17 623547-002
974543-001 Data Plate (Model No. 315.108340)... ........... 1 18 612999-001
2 969858-001 Gear and Spindle..................................... ........... 1 19 975141-001
3 999637-003 Bearing..................................................... ........... 1 975143-001
4 969373-002 Lower Blade Guard Support................... ........... 1 20 621433-018
5 974999-001 * Screw (#10-16 X 3/4 in. Pan Hd.)............. ........... 4 21 974802-001
6 975205-001 Logo Plate................................................ ........... 1 22 931744-059
7 968442-002 Fixed Blade Guard................................... ........... 1 23 621438-006
8 968702-011 * Screw (#8-16 x 3/4 in. Pan Hd.)............... ........... 3 24 621433-001
9 974900-001 Bumper................................. ................... .......... 1
10 989592-001 * Screw (#8-10 X 1-1/8 in. Fil. Hd.)............. ........... 1
25 941401-815
11 967952-001 Torsion Spring......................................... .......... 1
26 706404-007
12 974771-001 Lower Blade Guard Assembly................ ........... 1
27 614658-010
13 718602-804 Retaining Ring......................................... .......... 1
28 990147-001
14 999982-001 Inner Blade Washer................................. .......... 1
29 974716-001
15 Saw Blade 7-1/4 in. for 5/8 in. Arbor... .......... 1
972000-321
16 998463-001 Outer Blade Washer................................ .......... 1
Description Quan.
Spring Washer.................................................... 1
Blade Screw........................................................ 1
Logo Plate {Model No. 315.108330)...................1
Logo Plate (Model No. 315.108340)................... 1
Carriage Bolt (1/4-20 x 3-3/4 in.)........................ 1
Base Assembly................................................... 1
Washer................................................................. 2
Wing Nut “STD541625.........................................2
Carriage Bolt (1/4-20 x 5/8 in.)
“STD532507.........................................................
1
Roll Pin................................................................ 1
Hex Nut (#8-32) “STD541008............................. 1
* Screw (#8-32 x 5/8 in. Pan Hd.).......................... 1
Warning Tag........................................................ 1
Wrench................................................................. 1
Owner's Manual
NOTE; "A"- The assembly shown represents an important part of the Double Insulated System. To avoid the possibility of alteration or damage
to the system, service should be performed by your nearest Sears Repair Center. Contact your nearest Sears Retail Store for
Service Center information.
Standard Hardware Item — May Be Purchased Locally
Available From Div.98 — Source 980.00
Complete Assortment Available At Your Nearest Sears Retail Store
