Engine Parts
ZT 7000 - M ode! No. 107.277700
REF NO. PART NO. QTY. DESCRIPTION REF NO. PART NO. QTY. DESCRIPTION
IGNITION/ELECTRICAL - Group 5 4 12 227 19-S 1 Cap, drive end
1 12 086 14-S 1 Screw, hex. flange 5 12 170 05-S 1 Armature
M10x1.5x46 6 12 221 01-S 1 Kit, brush
2 12 468 03-S 1 Washer, plain 3/8" 7 12 227 13-S 1 Commutator, end cap
3 24 018 03-S 3 Retainer, grass screen 8 12211 01-S 2 Bolt, thru
4 24 162 03-S 1 Screen, grass
5 25 086 47-S 4 Bolt, shoulder FUEL SYSTEM - Group 8
6 12 157 06-S 1 Fan 1 M-641060-S 2 Nut, hex. flange M6x1.0
7 X-42-15-S 1 Key 2 M-629116-S 2 Stud M6x1.0x116
8 12 025 15-S 1 Flywheel 3 12 853 117-S 1 Kit, carburetor w/gaskets
9 41 403 09-S 1 Rectifier-regulator (Includes 4, 5 [qty. 1],
10 X-22-11-S 1 Washer, lock 1/4" Tie 12 454 03-S, and
11 12 086 42-S 2 Screw, tapping Terminal 25 452 20-S)
12 236602-S 1 Connector, rectifier-regula- 4 12 041 02-S 1 Gasket, air cleaner
tor (3 contact) 5 12 041 01-S 2 Gasket, carburetor
13 12 154 06-S 2 Clip, rectifier-regulator 6 12 265 06-S 1 Deflector, heat
14 M-548025-S 2 Screw, hex. cap M5x0.8x25 7 25 050 07-S 1 Filter, fuel
15 237878-S 1 Kit, stator (Includes 8 25 237 14-S 6 Clamp, fuel line
Terminal 25 452 01-S) 9 25 353 14-S 1 Line, fuel 7"
16 41 155 02-S 1 Connector (5 contact) 10 12 559 02-S 1 Kit, fuel pump (Includes 11
17 M-545010-S 2 Screw, hex. flange 15)
M5x0.8x10 11 12 294 13-S 1 Connector, 90°
18 X-728-1-S 2 Clip 12 25 153 04-S 1 O-Ring, fuel pump
19 12 132 02-S 1 Spark Plug 13 M-645020-S 2 Screw, hex. flange
20 12 584 04-S 1 Module, ignition M6x1.0x20
21 M-545020-S 2 Screw, hex. flange 14 25 294 09-S 1 Connector, straight hose
M5x0.8x20 15 12 353 01-S 1 Line, fuel 1-1/4"
NOT ILLUSTRATED 16 12 123 19-S 1 Line, fuel
25 518 05-S 1 Lead, black, rectifier to 17 M-545010-S 1 Screw, hex. flange
connector (5" -14 gauge M5x0.8x10
- uninsulated push on tab 18 12 154 01-S 1 Clamp, fuel line
terminals) 19 41 353 18-S 1 Line fuel 2-1/2"
12 51801-S 1 Lead, white, ground to kill NOT ILLUSTRATED
(19" -18 gauge-fully 12 757 02-S 1 Kit, float
insulated push on tab and 12 757 03-S 1 Kit, carburetor repair
uninsulated push on tab 12 757 33-S 1 Kit, solenoid repair
terminals) 12 757 37-S 1 Kit, bowl replacement
24 518 12-S 1 Lead, black (6" -12 gauge w/gaskets
- insulated grip barrel 12 518 24-S 1 Lead, red (18 gauge, - 20”
eyelet terminals) - insulated socket and
uninsulated push on tab
BLOWER HOUSING & BAFFLES Group 6 terminals)
1 M-545010-S 5 Screw, hex. flange 25 452 01-S 1 Terminal
M5x0.8x10 12 454 03-S 1 Tie, wire
2 24 468 10-S 1 Washer, plain 1/4" 25 454 03-S 3 Tie, wire
3 12 146 07-S 1 Plate, blower housing M-561010-S* 1 Screw, thread forming
4 M-645016-S 1 Screw, hex. flange M5x0.8x10
M6x1.0x16 X-22-11-S* 1 Washer, lock 1/4”
5 M-550010-S 1 Screw, hex. flange
M5x0.8x10 *Used to attach carburetor ground lead to carburetor baffle.
6 24 096 05-S 1 Cover, pinion
7 12 027 55-S 1 Housing, blower
8 12 063 18-S 1 Baffle, intake side
9 M-541050-S 1 Nut, hex. flange M5x0.8
10 25 154 02-S 3 Clip, mounting
11 12 086 37-S 3 Screw
12 12 063 20-S 1 Baffle, cylinder head
13 12 063 19-S 1 Baffle, cylinder
NOT ILLUSTRATED
12 113 119-S 1 Decal, 18 HP
STARTING SYSTEM - Group 7
1 M-839070-S 2 Screw, hex. flange
M8x1.25x70
2 12 098 22-S 1 Starter assembly (Includes
3-8)
3 12 755 53-S 1 Kit, drive
PTS - 31
