I
REPAIR PARTS LIS'
J
MODELS 486.421264/917.421264 PROFESSIONAL BRUSH GUARD
REF
QTY
PART NO.
DESCRIPTION
REF
QTY
PART NO.
DESCRIPTION
1
1
421265Y
Brush Guard Assembly
10
4
43082
Lock Nut, 3/8"
2
1
66696Y
Latch
11
2
1509-90
Hex Bolt, 1/4-20
X
1-1/4"
3
2
26729
Frame Brace
12
4
46978
Hex Nut (SIMS), 1/4"
4
4
43350
Carriage Bolt, 3/8-16 x 1"
13
2
42117
Spring
5
4
44072
Whiziock Nut, 3/8"
14
1
422753
Shroud
6
2
43001
Hex Bolt, 3/8-16x1"
15
2
422752
End Cap
7
2
43070
Washer, 3/8"
16
4
C-9M5732
Rivet
8
2
48106
Shoulder Bolt, 3/8-16
1
42035
Owners Manual
9
2
R19171616 Washer, .5312x1 x .0598"
Call 1 -866-576-8388 for missing parts or assembly help
DO NOT RETURN TO STORE
