FEATURES

LED FUNCTION OF CHARGER

YELLOW LIGHT “ON” AND RED

CHARGER

LIGHT FLASHING INDICATES

DEFECTIVE BAnERY PACK

RED LIGHT “ON”
INDICATES FAST

CHARGING MODE

GREEN LIGHT “ON” INDICATES FULLY

CHARGED AND SLOW CHARGING

TO MAINTAIN BATTERY PACK

Fig. 2

BATTERY PACK SHOWN ATTACHED TO CHARGER

MOUNTING CHARGER

See Figure 4.

Your charger has a “key hole” hanging feature for conve­
nient, space saving storage. Therefore, if desired, you can
mount your charger to a wall. Screws should be installed

so that center distances are 4-1/8 inches apart.

BATTERY PACK SHOWN

IN CHARGER

Fig. 3
