How to remove and replace parts
Freezer
compartment
lamp
NOTE
.pÌ3manflih-g:;Ìs;doi;re;:ln:the:feverses8Gjuéf} of.assembJv-- " ■ ■ : ■ ■ ■ ■ ■ ■
:Bb/slire:to;iinplug thé;ppwbr.p!Ligbefòre;disfì1an^^^ assembly.'-
iN.everfapply tseyere dor.ceto; dismantlelparts.lFMrfs.mayIbeldamaged;.:
Separate the lamp by pulling it out ©while
slightly striking ©and rotating ©the lamp cover.
Turn the bulb cxjunterclockwise. Max. 40 W bulb
for refrigerator is used and can be purchased at
a service center.
Freezer
compartment
shelf
Door rack and
support
To remove a shelf, push the shelf to the left ®,
lift the left part of the shelf a bit ®, lift the right
part up ©, and take it out.
Lift the door rack holding both sides ® and
pull it out @.
® ® III
^
I
... u
Ice storage bin
Hold the ice storage bin as shown in the right
figure and pull it out @ while slightly lifting it ®.
■ Do not dismantle the ice storage bin unless
it is necessary.
■ Use both hands to remove the ice bin to avoid
dropping it.
After dispenser
is used
The water collector has no self-drainage
function, so it should be cleaned regularly.
Remove the cover by pulling the front of the
water collector cover and dry it with a cloth.
