Model 109SS Temperature Probe
Example Program for CR10X
;{CR10X}
;
*Table 1 Program
01: 1
Execution
Interval
(seconds)
1: AC Half Bridge (P5)
1: 1
Reps
2: 25
2500 mV 60 Hz Rejection Range
3: 1
SE
Channel
4: 1
Excite all reps w/Exchan 1
5: 2500
mV
Excitation
6: 1
Loc [ V_Vx ]
7: 1.0
Mult
8: 0.0
Offset
2: Z=1/X (P42)
1: 1
X Loc [ V_Vx ]
2: 2
Z Loc [ Vx_V ]
3: Z=X+F (P34)
1: 2
X Loc [ Vx_V ]
2: -1
F
3: 3
Z Loc [ Vx_V_1 ]
4: Z=X*F (P37)
1: 3
X Loc [ Vx_V_1 ]
2: 24900
F
3: 4
Z Loc [ Rtherm ]
5: Z=LN(X) (P40)
1: 4
X Loc [ Rtherm ]
2: 5
Z Loc [ lnRt ]
6: Z=X*F (P37)
1: 5
X Loc [ lnRt ]
2:
.001
F
3: 6
Z Loc [ Scal_lnRt ]
7: Polynomial (P55)
1: 1
Reps
2: 6
X Loc [ Scal_lnRt ]
3: 7
F(X) Loc [ 1_Tk ]
4: .001129 C0
5: .234108 C1
6: 0.0
C2
7: 87.7547 C3
8: 0.0
C4
9: 0.0
C5
8: Z=1/X (P42)
1: 7
X Loc [ 1_Tk ]
2: 8
Z Loc [ Tk ]
8
