Specifications Troubleshooting
Television system
Channel coverage
Picture tube
Antenna
Input
(Only for
KV-19TS20/19TR20)
Output
(Only for KV-19TS20)
Power requirements
Power consumption
Accessories supplied
American TV standards
VHP: 2 - 1 3
UHF: 1 4 - 6 9
Cable TV: 1 - 1 2 5
Mirrorblack Trinitron tube
19- inch picture measured
diagonally
20- inch picture tube measured
diagonally
75-ohm external antenna terminal
for VHF/UHF
VIDEO INPUT (phono jacks)
Video: 1 Vp-p, 75-ohms
unbalanced, sync negative
Audio: 500 mVrms
(100% modulation)
Impedance: lOkilohms
AUDIO OUTPUT (VARIABLE)
(phono jacks)
More than 408 mVrms at the
maximum volume setting
(variable) (100% modulation)
120 V A C , 60 Hz
120 W (Max.)
5 W (in standby condition)
Disturbances in picture and sound can often be eliminated
by checking the symptoms and following the suggestions
listed below.
Remote Commander
19TS20 RM-783 (1)
with 2 size AA(R6)
batteries
19TS10 RM-782 (1)
19TR20 RM-781 (1)
19TR10 RM-780 (1)
2037RS RM-782 (1)
2027R RM-780 (1)
VHF/UHF telescopic
dipole antenna (1)
Antenna
connector (1)
19TS20 NO YES
19TS10 NO YES
19TR20 YES* YES
19TR10 YES* YES
2037RS NO YES
2027R YES YES
* Only for USA models.
Optional accessories U/V mixer EAC-66
Connecting cable
VMC-606/607M
VMC-810/820S
RK-74A
Designs and specifications are subject to change without
notice.
SYMPTOM CHECK AND ADJUST
Poor or no picture
(screen not lit),
good sound
• Adjust PICTURE.
• Adjust BRIGHT.
• Check antenna/cable
connections.
Good picture,
no sound
• Press VOLUME-f.
• Release MUTING on the
Remote Commander.
• Check that the MTS
button is set correctly.
• Check that the TV/
VIDEO button is set
correctly.
• Set the SPEAKER switch
to ON.
No picture (screen
not lit), no sound
• Is POWER switched on?
• Power in outlet?
• Check that the TV/
VIDEO button is set
correctly.
No color
• Is it a color program?
• Adjust COLOR.
Snow and noise
only
• Is it an active or the
correct channel?
• Check the CABLE
selector setting.
• Check antenna/cable
connections.
Bii;
Dotted
lines
or
stripes
This is often caused by
local interference, (e.g.
cars, neon signs,
hairdryers etc.) Adjust
antenna for minimum
interference.
^
1 Double
ghosts
Reflections from nearby
mountains or buildings
often cause this problem.
A highly directional
outdoor antenna or a
CATV cable may improve
the picture.
Try another channel. It could be station trouble.
Program start
TIMER and/or
channel BLOCK
does not operate
properly.
• Is the clock set correctly?
• Is the setting correct?
• Have you unplugged the
unit?
• Has a power failure
occurred?
If so. the settings have
been erased.
If the problem persists, contact your nearest service facility.
