23
Dutchwest Natural Vent Gas Heater
30002008
Dutchwest Natural Vent Gas Heater
(continued)
Models 2467, 2468
Ref. Description Part Number
8. End, Rt - DW Gas 30001927
9. End, Lt - DW Gas 30001926
10. Gasket, Glass Med. Knit - RDV40 1203702
11. Glass, DV25 1601691
12. Glass Frame Assembly SDV30 30000127
13. Manifold Tube Assembly - Double Bead 20003739
14a. Valve RN Honeywell VS8420E 2038 10001782
14b. Valve RP Honeywell VS9420E 2020 10001759
15a. Pilot Assembly 3Way N/DV Rn 0.199.706 10002264
15b. Pilot Assemlby 3Way RP 0.199.703 10002265
16. Thermocouple 24” 53373
7531137
17. Electrode Ignitor w/ cable SIT 24 10001297
18. Pilot Top Convertible 10002266
19. Thermopile 51827
7533113
20. Tubing Pilot w/Fitting SIT 10001296
21. Nut Electrode SIT #0.974.144 57886
22a. Orifice Hood #69 - 0.0292” (Front LP) 30000513
22b. Orifice Hood #54 (Front Natural) 20000130
22c. Orfice Hood #54 Rear LP 20000130
22d. Orfice Hood #44 Rear NG 30000334
23a. Orifice Pilot #62 NG Top Convertible 10002268
23b. Orifice Pilot #35 - LP Top Convertible 10002269
24. Burner Housing Assembly 20005264
25. Nut, Hex Jam 3/8 - 16 Top LK-Z 1203290
26. Front Pawl Assembly, Ash Door - ENC 5004025
27. Front Steel Handle/Shaft - NI/VER 5004237
28. Handle Package, Ceramic w/Screw 0004342
29. Grate Burner JDV 20002167
30a. Sensor Spill Switch, Bedroom 51866
30b. Spill Switch 20005039
31. Switch Rocker 30000874
32. Wire w/Straight Term 2 End 50” 10002582
33. Spill Switch Wire Assembly 30000108
34. Bracket - Right Log 20005259
35. Bracket - Left Log 20005258
37. Gasket Base Pan Inner 20002566
38. Interrupter block 30000069
39. Draft Hood/Flue Collector Assembly 20005227
Fuel Conversion Kits
Conversion Kit, NG to LP - 2467
Kit #000-5022
Conversion Kit, LP to NG - 2468 Kit #000-5021
