Sony KD-34XBR2 - Manual

SONY
KD-34XBR2
DESCRIPTION: 34" Trinitron® POWER
DIMENSIONS M
onitor/R ece i ve r requirem ENTS:120V AC
(WHD): 39 1 / 8 ” x 24 1/2” x 23 1/4” poWER 6°Hz
WEIGHT: 205 lbs CONSUMPTION33°w(max)
4w(stby)
FRONT VIEW
4 1/2”
<-------
30 3/16”
17 1/4”
39 1/8”
4 1/2”
------->
24 1/2”
4 1/2”
SIDE VIEW
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 986 3062 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
irsntmn HDTV
IR Sensor
