Page -52- CLARKE TECHNOLOGY Operator's Manual -SCRUBTEC 743 and 751
CLARKE TECHNOLOGY
SCRUBTEC 743 S, 743 L, 751 S and 751 L SCRUBTEC 743 S, 743 L, 751 S and 751 L SCRUBTEC 743 S, 743 L, 751 S and 751 L SCRUBTEC 743 S, 743 L, 751 S and 751 L SCRUBTEC 743 S, 743 L, 751 S and 751 L
Gearbox Assembly and Parts List 5/05
Ref # Part No. Description Qty
1 57846A Ring, Snap 1
2 507641 Seal, Oil, Small 1
3 52050A Cap End 1
4 56668A O-Ring 1
5 51176A Bearing, Large 1
7 902605 Bearing, Small 1
9 58144A Seal, Oil Large 1
10 NI Darina EP2 Grease 4 oz.
11 52855A Complete Gearbox Asm. 1
1
2
3
4
5
7
8
