2
Program Accessories
With Existing Network
Step 1: On the phone connected to the OTIU, press
“**07” after hearing the dial tone. Listen for double beep.
Hang up and Learn LED will flash for 15 seconds. If an
error tone is heard it means that memory will have to be
cleared (see Troubleshooting).
Step 2: Within 15 seconds enter Master PIN Number on
GAPLM.
Step 3: Press “05” and GAPLM will beep. The OTIU will
ring the telephone and Caller ID will display “Unit
Learned”.
Step 1: Set Dipswitch #1 on the DAILM to the
UP position to set the DAILM as a primary device.
Step 2: On the phone connected to the OTIU, press
“**07” after hearing the dial tone. Hang up and Learn
LED will flash for 15 seconds. If an error tone is heard it
means that memory will have to be cleared (see
Troubleshooting).
Step 3: Within 15 seconds, press and release the Learn
button on the DAILM.
Step 4: The OTIU will ring the telephone and Caller ID
will display “Unit Learned”.
Step 1: On the phone connected to the OTIU, press
“**07” after hearing the dial tone. Hang up and Learn
LED will flash for 15 seconds. If an error tone is heard it
means that memory will have to be cleared (see
Troubleshooting).
Step 2: Within 15 seconds press the Learn button on
ONE Repeater. The LED will light.
Step 3: The OTIU will ring the telephone and Caller ID
will display “Unit Learned”.
NOTE: If the Repeaters have not been programmed to
anything within an existing network, see Repeater
manual for further instructions.
NOTE: If programming into an existing network, ensure
the OTIU is programmed to the Active unit.
Repeaters
Gate Access Panel (GAPLM)
DAILM
