Crestron TPS-12G/15G/17G-QM Isys
®
G-Series Touchpanels
QM AUDIO OUTPUT SETUP
Refer to the following table for additional QM AUDIO OUTPUT SETUP menu
details.
QM Audio Output Setup Details
QM AUDIO
OUTPUT SETUP
SCREEN
CONTROL
DESCRIPTION
Program Gain
Adjusts the level of the QM output with the – and +
buttons.
Transmit QM ID
Allows transmission of touchpanel’s QM ID for use in QM
systems utilizing auto compensation*. Manual will
transmit a specific QM ID, adjustable with the Down and
Up Buttons. Auto, the default setting, will transmit the
Cresnet ID as the QM ID.
Speech EQ Trims
Adjust relative level of the QM output at four speech
related frequencies with the – and + buttons. These will
alter the tonality of the QM audio output.
* Auto compensation automatically recalls microphone EQ settings, source compensation settings and
peak and boost preset values of multiple QM origination points when acting as an endpoint.
