TECHNICAL SPECIFICATION
Power output
105 Watts per channel into 8Ω
127 Watts per channel into 6Ω
162 Watts per channel into 4Ω
Input sensitivity for 105 Watts into 8Ω
Line inputs (input 1 switch set to line) 1-5 and record - 196mV load 10K
Phono (input 1 switch set to phono) - 2mV Load 47K in parallel with 220pF
Direct input - 760mV Load 50K
Power amplifier gain - 31.6dB
Record output - 196mV for rated inputs
Pre-amplifier output - 760mV for rated inputs
Dimensions in mm - W432 x H82 x D340
Weight - 13kg
