6
Input 2-5 – Standard “Line level” Line inputs enable the connection of any
additional sources such as CD players DVD, TUNER etc. Note the record output
is disabled when input 5 is selected.
Input 5 – Record input “line level” We advise if a recording device with the
ability to monitor the recording signal is connected to the amplifier, its output
is connected to input 5 to stop possible feedback issues.
Record output For connection to any recordable device (such as a CD
recorder). The output is a ‘record signal’ as selected by the main input selector
1-4. Note the record output is disabled when input 5 is selected. This output is
not affected by the volume control.
Mains Power lead The supplied power lead should be connected to the ‘Power
in’ socket also located on the rear of the unit.
LOUDSPEAKER CONNECTIONS
The Brio- R is capable of driving all normal Hi-Fi loudspeakers, Rega
recommends using loudspeakers with a nominal impedance of 8Ω. It is possible
to run speakers as low as 4Ω however such units may cause the case to exceed
40° C above the ambient temperature.
Top row RED and BLACK left speaker
Bottom row RED and BLACK right speaker
