9
Reverse With Confidence
Installation Guide
Camera
1. Attach camera bracket close to rear marker lights, centered
on vehicle.
2. Attach camera to bracket using screws provided and adjust
the angle.
Cable
1. Be sure to position the cable properly. The aviation camera
cable uses aircraft grade connectors which means the camera
cable can be exposed to all weather elements, do not run the
cable over sharp edges, do not kink the cable and keep away
from HOT and rotating parts.
2. Fasten all cable and secure all excess cable.
Monitor
1. The Mirror Monitor replaces the existing rear view mirror in
vehicle.
2. Replace existing mirror, and adjust mounting angle to allow
optimum driver viewing comfort. (see figure 1.1 on page 12).
