Reverse With Confidence ™
Wiring Camera & Monitor
• Audio works on two ports of
multiplexer and positive triggers
must be triggered for audio to
operate.
#3 Port labeled “backup”
(blue trigger) #2 port labeled
“DVD” (white Trigger).
• When installing a TWO (2)
camera setup, use ports #3 and
#2 and use positive triggers
Blue and White.
• There is a built-in voltage
regulator for our systems which
can handle 12-24 volts real
consumption is 10 to 30 Volts.
• When installing all THREE (3)
cameras, use all three ports and
connect all positive triggers to
appropriate connections.
✦ To automatically have camera
and monitor turn ON when
vehicle activates, simply twist
BLUE positive trigger 12V+ to
Red Power line 12V+ and wire
to ignition power which can
be an accessory switch/fuse
line and black wire 12V- to
chassis ground.
✦ Infrared technology built into
camera IRs are activated auto-
matically according to the
lighting conditions.
✦ When using the postive trigger
functions (blue, yellow & white
wires) each trigger function
needs to work on a seperate
12V+ source i.e. the Yellow
and White wires can be wired
to a turn signal circuit etc.
✦ Grid lines function can be
turned on/off by pushing
MENU 8 times and than select
ON/OFF
