Guiding by using QHY5 in PHD
1. Connect the QHY5 and the equatorial
mount’s guide spot.
2. Run PHD, choose Connect to Camera ( )-
ASCOM v5 camera-CMOS QHY5 Camera-
Properties, set Gain, click OK to return.
3. Choose Mount-On-camera, and then click
Connect to telescope ( ).
4. Click to expose. You can change the
expose time at the pull-down menu, and
change
the screen luminance with
changing the slider’s position.
5. Find a star in the realtime image, click
it, the star will be marked by a green
box.
6. Click to start guiding.
7. Choose Tools-Enable Graph to show the
guiding graph.
QHY5 Guiding Port Definition
QHY5 uses the ST-4 guiding port, you can
watch the under picture to know detail.
