ProTemp PT-70-SS - Manual (Page 2)

Table of Contents
Warnings.................................................................. 2
Safety Information ................................................ 2-3
Specifications .......................................................... 3
Features .................................................................. 4
Theory of Operation ................................................ 5
Unpacking................................................................ 5
Fuels........................................................................ 5
Ventilation................................................................ 6
Operation................................................................. 6
Maintenance......................................................... 6-7
Storage .................................................................... 7
Exploded Parts Drawing.......................................... 8
Replacement Part Listing ....................................... 9
Wiring Diagrams.................................................... 10
Troubleshooting ..................................................... 11
Warranty .................................................. Back Page
Safety Information
This is a kerosene, direct-fired, forced air heater. It is
primarily intended for use for temporary heating of build-
ings under construction, alteration or repair. Direct-fired
means that all of the combustion products of the heater
enter the heated space. This appliance is rated at 98%
combustion efficiency, but does produce small amounts of
carbon monoxide. Carbon monoxide is toxic. Humans
can tolerate small amounts of carbon monoxide, and
precautions should be taken to provide proper ventilation.
Failure to provide proper ventilation in according to this
manual can result in death. Early signs of carbon
monoxide poisoning resemble the flu. Symptoms of
improper ventilation are:
* headache * dizziness * burning of the nose and eyes
* nausea * dry mouth * sore throat *
If the heater is being used in the presence of others, be
sure to inform them of all proper safety precautions,
operating procedures and hazards. Some people are
more affected by carbon monoxide than others. These
are pregnant women, people with heart or lung disease or
anemia, those under the influence of alcohol or at high
altitudes.
- Check the heater thoroughly for damage before each
use. DO NOT operate a damaged heater.
- DO NOT modify this heater or operate a heater that has
been modified from it’s original state.
- NEVER use gasoline, naphtha, paint thinner, alcohol or
other fuels of any kind to operate this heater.
- Suitable for outdoor use. Provide at least 3 square feet
of opening per 100,000 Btu of rated operation (See
page 6).
- Keep heater area free from combustible materials such
as gasoline, paint thinners and other flammable vapors
and liquids. Dust is combustible. Do not use heater in
areas of high dust concentration.
Minimum clearance from Combustibles:
Top Sides Front
70k 4 ft. 4 ft. 8 ft.
Ultra-Portable Oil-
Fired Radiant Heater
NEVER LEAVE HEATER
UNATTENDED WHILE BURN-
ING, OR WHILE CONNECTED
TO A POWER SOURCE.
Page 2
Pinnacle Products International, Inc. Ultra-Portable Kerosene User’s Manual
Carbon Monoxide poisoning may lead to
death!
DANGER
California Residents: Combustion
by-products produced when using this
product contain carbon monoxide, a chemical known to
the state of California to cause cancer and birth defects
(or other reproductive harm).
This product contains chemicals,
including lead, known to the State of
California to cause birth defects or other reproductive
harm. Wash hands after handling.
Do not operate this heater until you
have read, and thoroughly understand
these safety and operating instructions.
Massachusetts Residents: Massachusetts state
law prohibits the use of this heater in any building which is
used in whole or in part for human habitation. Use of this
heating device in Massachusetts requires local fire
department permit (M.G.L.C. 148, Section 10A).
New York City Residents: The New York City Fire
Code prohibits the storage, handling and use of kerosene
fueled heaters for space heating. Any person violating
that provision may be punished by a fine up to $10,000
and a term of imprisonment up to 6 months.
This is an unvented portable heater. It
uses air (oxygen) from the area in
which it is used. Adequate combustion and ventilation air
must be provided. Refer to VENTILATION Page 6.
WARNING
This heater is not suitable for use with
Bio-Diesel; use of Bio-Diesel will
damage the filter and seals. Damage caused by use of
Bio-Diesel will not be covered by warranty.
WARNING
WARNING
WARNING
WARNING
FIRE, BURN, INHALATION, AND
EXPLOSION HAZARD. KEEP
SOLID COMBUSTIBLES, SUCH AS BUILDING
MATERIALS, PAPER OR CARDBOARD, A
SAFE DISTANCE AWAY FROM THE HEATER
AS RECOMMENDED BY THESE INSTRUC-
TIONS. NEVER USE THE HEATER IN SPACES
WHICH DO OR MAY CONTAIN VOLATILE OR
AIRBORNE COMBUSTIBLES, OR PRODUCTS
SUCH AS GASOLINE,
SOLVENTS, PAINT THINNERS, DUST
PARTICLES OR UNKNOWN CHEMICALS.
NOT FOR HOME OR
RECREATIONAL USE.
WARNING
WARNING
