Pro-Ject Juke Box Esprit
Controls, features and connections
1 Motor
2 Stepped drive pulley
3 Drive belt * 3a Hook *
4 Hub
5 Platter *
6 Tonearm counterweight * 6a Downforce scale
7 Tonearm lift lever
8/18 Tonearm rest and removable transport lock
9
Tonearm tube 9a Tonearm base
10 Lid *
11 Lid hinges
12 Hinge fasteners
13 Power supply socket 16V 13a Power supply socket 21V
14 Speaker connector 14a Line level inputs
15 Anti-skating weight adjustment scale
16 Anti-skating weight *
17 Anti-skating weight support hoop
20 Power switch 20a Start/stop switch (motor)
21 Headshell with finger lift and fitted Ortofon Alpha cartridge
22 Single adapter *
23 3,5mm connector *
16V and 21V power supply (not shown) *
Dear music lover,
thank you for purchasing a PRO-JECT AUDIO record player.
In order to achieve maximum performance and reliability with this record player you should study these instructions
for use carefully.
!
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable
receptacle. Before starting assembly make yourself acquainted with the parts listed above and correspondingly
numbered in the technical drawings above. Separately packed items are marked with an asterisk *.
Set-up
The deck is supplied partially disassembled and carefully packaged for safe transport. Carefully remove all
parts from the transport packaging.
Make sure the surface you wish to use the turntable on is level (use a spirit level) before placing the turntable on it.
Remove the transport lock (18) from the tonearm. Store it in the original packaging so it is are available for
any future transportation.
Fit the drive belt (3) around the hub (4) and the smaller diameter part of the motor pulley (2). Avoid getting
sweat or grease on the belt as these will deteriorate the performance and reduce the belt's lifespan. Use
absorbent kitchen paper to remove any oil or grease from the outer edge of the hub and the belt. Fit the
platter (5) over the spindle of the hub (4).
We recommend to use the record player without a mat on the platter.
