PAGE 19
Model：TM150F7E
Items Specifications
Size (diagonal) 15.0 inch
High Brightness
High Contrast
Wide Angle of View
High Speed Response
Long Lamp Life
Native Resolution 1024 X 768
Pixel Pitch 0.297mm(H) X0.297mm (V)
Number of Dots 1024 X RGB X 768
Viewable Area 304.1mm(H) x 228.1mm (V)
LCD panel items
Color Display 16.2million
Color System PAL, SECAM, NTSC
Sound System DK, I, BG, L/L’
PC Displayable Input Format VGA / SVGA /XGA
YPbPr Input Format
480i, 480p, 576i, 576p, 720p, 1080i,
1080p(50Hz, 60Hz)
Audio Power Output 2 x 2.0 W
AV-Audio Input 1 (shared with RGB)
AV-Video Input 1
Earphone Output 1
PAL/NTSC Digital Comb Filter YES
RGB Input 1
YPbPr Input 1 (with audio input)
VGA Video Input 1
VGA Audio Input 1
AC Voltage Input
Rated Power Consumption
Please refer to the back label
Standby Power Consumption ≤1.5W
Unit Dimension
454mm(W)×343mm(H)×166mm(D)
（including the pedestal stand）
Unit Weight 4.5kg(Approx.)
SPECIFICATIONS
