DR
4 -Ton WOOD SPLITTER Safety & Operating Instructions
23
Chapter 7: Parts Lists and Schematic Diagrams
DR 4 -Ton Electric Wood Splitter - Parts List
Note: Part numbers listed are available through Country Home Products.
Ref# Part# Description
01
204271 Hex Nut, M14
02
204281 Hex Nut (Thin), M14
03 204291 Piston,
Ram
04 204301 Spring
05 204311 O-ring,
Oil
Seal
06 204321 Piston
07 204341 O-ring,
Oil
Seal
08
204351 Square Piston Ring
09 204361 Cylinder
Body
10 182181 Dipstick
11 182191 O-ring,
Oil
Seal
12
202161 Ring, Seal, Teflon
13 202171 O-ring,
Oil
Seal
14
202141 Bleed Screw, M4 x 10
15
204371 End Cover, Oil Cylinder
16
182161 Bolt, Two Head
17
182151 Bolt, Two Head, Long
18
182291 Cover, Motor Fan, End
19 204381 Circlip,
Spindle
20 182301 Fan,
Flying
21
204421 Washer, Flat, M4
22
204411 Washer, Spring, M4
23
204401 Screw, Phillips, M4 x 6
24 202701 Motor
25 204681 Nut,
M8
26 204691 Screw,
M8
27 204801 O-ring,
Oil
Seal
28 202491 Washer,
Flat,
M8
29
204771 Washer, Spring, M8
30
204791 Bolt, M8 x 30
31
204651 Foot, Motor, Rubber, Right
32
203721 Foot, Motor, Rubber, Left
33 204571 Screw,
Phillips
Ref# Part# Description
34
182411 Cover, Capacitor Box
35
204551 Seal, Rubber, Anti-Dust
36 204581 Clamp,
Wire
37 205521 Switch
38
204521 Screw, Phillips, M4 x 8
39 204511 Connection
Pole
40 182211 Capacitor
41 204541 Washer,
Lock
42 204531 Nut,
M8
43
204501 Screw, Phillips, M4 x 12
44 204491 Support,
Capacitor
45
205651 Nut, Wire Clamp
46
205641 Bushing, Wire Clamp
47
182131 Power Cable & Plug
48
202481 Allen Head Bolt, M8 x 14
49
205921 Plate, Sleeve, Plastic
50
205941 Cover Seal, Square
51
205021 Screw, Fixing, M8 x 10
52 202751 Base,
Handle
53
205031 Short Bar, Handle
54
206121 Bar, Grip Handle, Long
55 205041 Spring
56
182111 Cover, Oil Cylinder, Front
57 205081 Washer,
Copper
58 205091 Nut
M10
59 205151 Washer,
Flat,
M10
60 203731 Nut,
M10
61
205131 Cover, Axle, Wheel
62 202681 Circlip,
Axle
63 205141 Wheel,
Rubber
64 203701 Frame,
Wheel
65 203741 Plate,
Support
66
204871 Log Pusher Assembly
