HUSB Installation Manual
Doc No. 910-00003-01 Rev 05
Page 5 of 6
Figure 5. Configuring Network ID
2. Press the top or bottom button to change the network ID to the required value.
The network ID cannot have a “0” value.
3. Press middle button to confirm the network ID.
The HUSB will automatically exit the programming mode if no key is pressed for
one minute.
4. Replace the front cover upon completion of the programming.
5. The network ID can be changed any time by following steps one through four.
When the HUSB is working normally, it will display the network ID currently in use.
3. Troubleshooting
The HUSB is designed with the following diagnostic functions to detect and diagnose
faults:
Code Reason Solution
E2
Radio error – Not able to
send/receive data
Restart the unit with removing and
inserting the USB cable to the WPT
Green Box.
If the error continues the device
requires replacement. Contact the
distributor.
E3
Ping Error – Not able to
locate a free RF channel to
use due to high RF
interference
Change the position of the Hub.
E4
Connect error – Not able to
connect to the nearest
repeater
The HUSB auto recovers after a few
refresh cycles, if this error occurs after
successful installation.
Consider adding/ changing the repeater
location in the zone, if the error persists.
E5
USB Error – Not able to
communicate with the WPT
Green Box
Check USB cable.
Change to a different USB port.
Replace the HUSB if problem persists.
4. Repair
The HUSB does not have any replacement or repairable parts. Contact the original
distributor of the unit for repair or warranty service.
