Dell S2240M Monitor - Manual

Dell Display Manager User's Guide
Dell™ Display Manager User's Guide
Overview
Using the Quick Settings Dialog
Setting Basic Display Functions
Assigning Preset Modes to Applications
Applying Energy Conservation Features
Overview
Dell Display Manager is a Windows application used to manage a monitor or a group of monitors. It allows manual adjustment
of the displayed image, assignment of automatic settings, energy management, window organization, image rotation and
other features on select Dell models. Once installed, Dell Display Manager will run each time the system starts and will place
its icon in the notification tray. Information about monitors connected to the system is always available when hovering over
the notification tray icon.
Using the Quick Settings Dialog
Clicking Dell Display Manager's notification tray icon opens the Quick Settings dialog box. When more than one supported Dell
model is connected to the system, a specific target monitor can be selected using the menu provided. The Quick Settings
dialog box allows convenient adjustment of the monitor's Brightness and Contrast levels, Preset Modes can be manually
selected or set to Auto Mode, and the screen resolution can be changed.
The Quick Settings dialog box also provides access to Dell Display Manager's advanced user interface which is used to adjust
Basic functions, configure Auto Mode and access other features.
Setting Basic Display Functions
