Set Up Laser Touch on Your Projector
4
Part B: Mount the Projector
2 Install the wall mount and the projector.
NOTE: The wall mount is shipped with your
projector. Please refer "wall mount
installation instructions".
NOTE: Project at 87" for a maximum image
size projection or ~84" if you would like to
leave a border around the projector image
for optimal touch experience.
Part C: Attach Laser Curtain Kit
3 Attach the laser curtain kit onto the
whiteboard.
NOTES:
a Attachment is aided with locating pin
and magnets.
b You can also lock the kit in place with a
security screw.
c There is a cover for the laser curtain kit.
(b) Screw
(a)
S520 Laser Touch QSC_A02-APCC.book Page 4 Thursday, May 8, 2014 4:54 PM
