Dell™ Display Manager User’s Guide

1
Dell™ Display Manager User’s Guide
• Overview
• Using the Quick Settings Dialog
• Setting Basic Display Functions
• Assigning Preset Modes to Applications
• Applying Energy Conservation Features
• Organizing windows with Easy Arrange
Overview
NOTE: DDM is not supported in DP1.2/ MST (Daisy Chain)
Dell Display Manager is a Windows application used to manage a monitor
or a group of monitors. It allows manual adjustment of the displayed
image, assignment of automatic settings, energy management, window
organization, image rotation and other features on select Dell models. Once
installed, Dell Display Manager will run each time the system starts and will
place its icon in the notification tray. Information about monitors connected
to the system is always available when hovering over the notification tray
icon.
Using the Quick Settings Dialog
Clicking Dell Display Manager’s notification tray icon opens the Quick
Settings dialog box. When more than one supported Dell model is
connected to the system, a specific target monitor can be selected using
the menu provided. The Quick Settings dialog box allows convenient
adjustment of the monitor’s Brightness and Contrast levels, Preset Modes can
be manually selected or set to Auto Mode, and the screen resolution can be
changed.
