Bottom View
Bottom view
Monitor Specifications
Power Management Modes
If you have VESA's DPMS™ compliance display card or software installed in your computer, the monitor can automatically reduce its power consumption when
not in use. This is referred to as Power Save Mode. If input from a keyboard, mouse or other input devices is detected by the computer, the monitor will
automatically "wake up". The following table shows the power consumption and signaling of this automatic power-saving feature:
E170S
Right side Left side
Label Description
1 AC power cord connector
2 VGA connector
VESA Modes Horizontal
Sync
Vertical Sync Video Power
Indicator
Power Consumption
Normal operation Active Active Active Green 25 W (maximum)
17 W (typical)
Active-off mode Inactive Inactive Blanked Amber Less than 1 W
