Statement of Volatility – Dell P2211H Monitor
The purpose of this document is to certify that Dell’s P2211H monitor will not save, retain or reproduce
a signal to any internal or external component after power has been removed and reapplied to the unit.
The Dell P2211H monitor contains non-volatile (NV) memory ICs. Non-volatile memory ICs continue to
retain their data even after the power has been removed. However, no input video data is written into
these memory ICs during operation.
List below contains volatile and non volatile memory ICs used in Dell P2211H monitor.
Flash ROM NA
Size 16 Mbit
Type [e.g. Flash PROM, EEPROM] Serial flash memory
Volatility
Non-volatile
Can user programs or operating
system write data to it during
normal operation?
No
Purpose To store firmware
How is data input to this
memory? Loading flash memory requires a vendor-provided
firmware file
How is this memory write
protected?
Software write protected
DDR SDRAM NA
Size 8x16 Mbit
Type [e.g. Flash PROM, EEPROM] DDR SDRAM
Volatility Volatile
Can user programs or operating
system write data to it during
normal operation?
No
Purpose Buffer of video decoder
How is data input to this
memory? Video is received by video decoder chip(CVBS processor)
and processed in SDRAM.
How is this memory write
protected?
No write protect mechanism
DDR2 SDRAM NA
Size 32x16 Mbit
Type [e.g. Flash PROM, EEPROM] DDR2 SDRAM
